型号 |
内径mm |
外径mm |
宽度mm |
扭矩Nm |
极限转速[rpm] |
重量kg |
FPD427M |
15mm |
31mm |
34mm |
94[Nm] |
2,000 |
0.09 |
FPD427Z |
15mm |
31mm |
34mm |
84[Nm] |
2,000 |
0.09 |
FPD432M |
20mm |
36mm |
34mm |
133[Nm] |
1,800 |
0.12 |
FPD432Z |
20mm |
36mm |
34mm |
121[Nm] |
1,800 |
0.12 |
FPD437M |
25mm |
41mm |
34mm |
176[Nm] |
1,700 |
0.15 |
FPD437Z |
25mm |
41mm |
34mm |
160[Nm] |
1,700 |
0.15 |
FPD442M |
30mm |
46mm |
34mm |
223[Nm] |
1,500 |
0.18 |
FPD442Z |
30mm |
46mm |
34mm |
208[Nm] |
1,500 |
0.18 |
FPD448M |
35mm |
53mm |
34mm |
286[Nm] |
1,300 |
0.23 |
FPD448Z |
35mm |
53mm |
34mm |
262[Nm] |
1,300 |
0.23 |
FPD453M |
40mm |
58mm |
34mm |
343[Nm] |
1,200 |
0.26 |
FPD453Z |
40mm |
58mm |
34mm |
314[Nm] |
1,200 |
0.26 |
FPD463M |
50mm |
68mm |
34mm |
461[Nm] |
1,100 |
0.34 |
FPD463Z |
50mm |
68mm |
34mm |
428[Nm] |
1,100 |
0.34 |
FPD473M |
60mm |
78mm |
34mm |
588[Nm] |
1,000 |
0.41 |
FPD473Z |
60mm |
78mm |
34mm |
543[Nm] |
1,000 |
0.41 |
FND437M |
15mm |
41mm |
34mm |
176[Nm] |
1,700 |
0.24 |
FND437Z |
15mm |
41mm |
34mm |
161[Nm] |
1,700 |
0.24 |
FND442M |
20mm |
46mm |
34mm |
223[Nm] |
1,500 |
0.28 |
FND442Z |
20mm |
46mm |
34mm |
208[Nm] |
1,500 |
0.28 |
FND453M |
25mm |
58mm |
34mm |
343[Nm] |
1,200 |
0.46 |
FND453Z |
25mm |
58mm |
34mm |
314[Nm] |
1,200 |
0.46 |
FND459M |
30mm |
64mm |
34mm |
411[Nm] |
1,100 |
0.55 |
FND459Z |
30mm |
64mm |
34mm |
381[Nm] |
1,100 |
0.55 |
FND463M |
35mm |
68mm |
34mm |
462[Nm] |
1,100 |
0.6 |
FND463Z |
35mm |
68mm |
34mm |
428[Nm] |
1,100 |
0.6 |
FND470M |
40mm |
75mm |
34mm |
550[Nm] |
1,000 |
0.69 |
FND470Z |
40mm |
75mm |
34mm |
509[Nm] |
1,000 |
0.69 |
FND473M |
45mm |
78mm |
34mm |
588[Nm] |
1,000 |
0.73 |
FND473Z |
45mm |
78mm |
34mm |
543[Nm] |
1,000 |
0.73 |
RA437Z |
15mm |
65mm |
32mm |
161[Nm] |
1,700 |
0.81 |
RA442Z |
20mm |
75mm |
36mm |
208[Nm] |
1,500 |
1.08 |
RA453Z |
25mm |
90mm |
45mm |
314[Nm] |
1,200 |
1.5 |
RA459Z |
30mm |
100mm |
50mm |
381[Nm] |
1,100 |
1.81 |
RA463Z |
35mm |
100mm |
50mm |
428[Nm] |
1,100 |
1.75 |
RA470Z |
40mm |
110mm |
50mm |
509[Nm] |
1,000 |
2.28 |
RA473Z |
45mm |
110mm |
50mm |
543[Nm] |
1,000 |
2.2 |
FP422M |
10mm |
26mm |
27mm |
60[Nm] |
10,100 |
0.07 |
FP422Z |
10mm |
26mm |
27mm |
53[Nm] |
10,100 |
0.07 |
FP427M |
15mm |
31mm |
27mm |
94[Nm] |
7,400 |
0.08 |
FP427Z |
15mm |
31mm |
27mm |
84[Nm] |
7,400 |
0.08 |
FP432M |
20mm |
36mm |
27mm |
133[Nm] |
5,900 |
0.1 |
FP432Z |
20mm |
36mm |
27mm |
121[Nm] |
5,900 |
0.1 |
FP437M |
25mm |
41mm |
27mm |
176[Nm] |
4,800 |
0.12 |
FP437Z |
25mm |
41mm |
27mm |
160[Nm] |
4,800 |
0.12 |
FP442M |
30mm |
46mm |
27mm |
223[Nm] |
4,200 |
0.14 |
FP442Z |
30mm |
46mm |
27mm |
208[Nm] |
4,200 |
0.14 |
FP448M |
35mm |
53mm |
27mm |
286[Nm] |
4,300 |
0.19 |
FP448Z |
35mm |
53mm |
27mm |
262[Nm] |
4,300 |
0.19 |
FP453M |
40mm |
58mm |
27mm |
343[Nm] |
3,400 |
0.21 |
FP453Z |
40mm |
58mm |
27mm |
314[Nm] |
3,400 |
0.21 |
FP463M |
50mm |
68mm |
27mm |
461[Nm] |
2,900 |
0.25 |
FP463Z |
50mm |
68mm |
27mm |
428[Nm] |
2,900 |
0.25 |
FP473M |
60mm |
78mm |
27mm |
588[Nm] |
2,500 |
0.3 |
FP473Z |
60mm |
78mm |
27mm |
543[Nm] |
2,500 |
0.3 |
FN437M |
15mm |
41mm |
27mm |
176[Nm] |
4,800 |
0.19 |
FN437Z |
15mm |
41mm |
27mm |
160[Nm] |
4,800 |
0.19 |
FN442M |
20mm |
46mm |
27mm |
223[Nm] |
4,200 |
0.22 |
FN442Z |
20mm |
46mm |
27mm |
208[Nm] |
4,200 |
0.22 |
FN453M |
25mm |
58mm |
27mm |
343[Nm] |
3,400 |
0.36 |
FN453Z |
25mm |
58mm |
27mm |
314[Nm] |
3,400 |
0.36 |
FN459M |
30mm |
64mm |
27mm |
411[Nm] |
3,000 |
0.43 |
FN459Z |
30mm |
64mm |
27mm |
381[Nm] |
3,000 |
0.43 |
FN463M |
35mm |
68mm |
27mm |
461[Nm] |
2,900 |
0.47 |
FN463Z |
35mm |
68mm |
27mm |
427[Nm] |
2,900 |
0.47 |
FN470M |
40mm |
75mm |
27mm |
550[Nm] |
2,600 |
0.54 |
FN470Z |
40mm |
75mm |
27mm |
509[Nm] |
2,600 |
0.54 |
FN473M |
45mm |
78mm |
27mm |
588[Nm] |
2,500 |
0.58 |
FN473Z |
45mm |
78mm |
27mm |
544[Nm] |
2,500 |
0.58 |
FK6203 |
17mm |
40mm |
12mm |
53[Nm] |
10,800 |
0.07 |
FK6203-RS |
17mm |
40mm |
12mm |
53[Nm] |
3,700 |
0.07 |
FK6204 |
20mm |
47mm |
14mm |
60[Nm] |
7,500 |
0.12 |
FK6204-2RS |
20mm |
47mm |
14mm |
60[Nm] |
3,200 |
0.12 |
FK6205 |
25mm |
52mm |
15mm |
104[Nm] |
5,400 |
0.15 |
FK6205-2RS |
25mm |
52mm |
15mm |
104[Nm] |
2,800 |
0.15 |
FK6206 |
30mm |
62mm |
16mm |
148[Nm] |
5,100 |
0.23 |
FK6206-2RS |
30mm |
62mm |
16mm |
148[Nm] |
2,400 |
0.23 |
FK6207 |
35mm |
72mm |
17mm |
265[Nm] |
3,700 |
0.34 |
FK6207-2RS |
35mm |
72mm |
17mm |
265[Nm] |
1,900 |
0.34 |
FK6208 |
40mm |
80mm |
18mm |
267[Nm] |
3,700 |
0.45 |
FK6208-2RS |
40mm |
80mm |
18mm |
267[Nm] |
1,900 |
0.45 |
FK6304-2RS |
20mm |
52mm |
15mm |
104[Nm] |
2,800 |
0.17 |
FKN6203 |
17mm |
40mm |
12mm |
53[Nm] |
10,800 |
0.07 |
FKN6203-RS |
17mm |
40mm |
12mm |
53[Nm] |
3,700 |
0.07 |
FKN6204 |
20mm |
47mm |
14mm |
60[Nm] |
7,500 |
0.12 |
FKN6204-2RS |
20mm |
47mm |
14mm |
60[Nm] |
3,200 |
0.12 |
FKN6205 |
25mm |
52mm |
15mm |
104[Nm] |
5,400 |
0.15 |
FKN6205-2RS |
25mm |
52mm |
15mm |
104[Nm] |
2,800 |
0.15 |
FKN6206 |
30mm |
62mm |
16mm |
148[Nm] |
5,100 |
0.23 |
FKN6206-2RS |
30mm |
62mm |
16mm |
148[Nm] |
2,400 |
0.23 |
FKN6207 |
35mm |
72mm |
17mm |
265[Nm] |
3,700 |
0.33 |
FKN6207-2RS |
35mm |
72mm |
17mm |
265[Nm] |
1,900 |
0.33 |
FKN6208 |
40mm |
80mm |
18mm |
267[Nm] |
3,700 |
0.45 |
FKN6208-2RS |
40mm |
80mm |
18mm |
267[Nm] |
1,900 |
0.45 |
FKNN6203 |
17mm |
40mm |
12mm |
53[Nm] |
10,800 |
0.07 |
FKNN6203-RS |
17mm |
40mm |
12mm |
53[Nm] |
3,700 |
0.07 |
FKNN6204 |
20mm |
47mm |
14mm |
60[Nm] |
7,500 |
0.12 |
FKNN6204-2RS |
20mm |
47mm |
14mm |
60[Nm] |
3,200 |
0.12 |
FKNN6205 |
25mm |
52mm |
15mm |
104[Nm] |
5,400 |
0.14 |
FKNN6205-2RS |
25mm |
52mm |
15mm |
104[Nm] |
2,800 |
0.14 |
FKNN6206 |
30mm |
62mm |
16mm |
148[Nm] |
5,100 |
0.22 |
FKNN6206-2RS |
30mm |
62mm |
16mm |
148[Nm] |
2,400 |
0.22 |
FKNN6028 |
40mm |
80mm |
18mm |
267[Nm] |
3,700 |
0.44 |
FKNN6208-2RS |
40mm |
80mm |
18mm |
267[Nm] |
1,900 |
0.44 |
FKNN6304-2RS |
20mm |
52mm |
15mm |
104[Nm] |
2,800 |
0.15 |
FR422M |
10mm |
26mm |
12mm |
60[Nm] |
10,100 |
0.03 |
FR422Z |
10mm |
26mm |
12mm |
53[Nm] |
10,100 |
0.03 |
FR427M |
15mm |
31mm |
12mm |
92[Nm] |
7,400 |
0.04 |
FR427Z |
15mm |
31mm |
12mm |
83[Nm] |
7,400 |
0.04 |
FR432M |
20mm |
36mm |
12mm |
128[Nm] |
5,900 |
0.05 |
FR432Z |
20mm |
36mm |
12mm |
117[Nm] |
5,900 |
0.05 |
FR437M |
25mm |
41mm |
12mm |
169[Nm] |
4,800 |
0.06 |
FR437Z |
25mm |
41mm |
12mm |
154[Nm] |
4,800 |
0.06 |
FR442M |
30mm |
46mm |
12mm |
212[Nm] |
4,200 |
0.07 |
FR442Z |
30mm |
46mm |
12mm |
198[Nm] |
4,200 |
0.07 |
FR448M |
35mm |
53mm |
12mm |
272[Nm] |
4,300 |
0.09 |
FR448Z |
35mm |
53mm |
12mm |
248[Nm] |
4,300 |
0.09 |
FR453M |
40mm |
58mm |
12mm |
321[Nm] |
3,400 |
0.1 |
FR453Z |
40mm |
58mm |
12mm |
294[Nm] |
3,400 |
0.1 |
FR463M |
50mm |
68mm |
12mm |
427[Nm] |
2,900 |
0.12 |
FR463Z |
50mm |
68mm |
12mm |
394[Nm] |
2,900 |
0.12 |
FR473M |
60mm |
78mm |
12mm |
539[Nm] |
2,500 |
0.14 |
FR473Z |
60mm |
78mm |
12mm |
496[Nm] |
2,500 |
0.14 |
FRN427M |
10mm |
31mm |
12mm |
92[Nm] |
7,400 |
0.05 |
FRN427Z |
10mm |
31mm |
12mm |
83[Nm] |
7,400 |
0.05 |
FRN432M |
12mm |
36mm |
12mm |
128[Nm] |
5,900 |
0.07 |
FRN432Z |
12mm |
36mm |
12mm |
117[Nm] |
5,900 |
0.07 |
FRN437M |
15mm |
41mm |
12mm |
169[Nm] |
4,800 |
0.08 |
FRN437Z |
15mm |
41mm |
12mm |
154[Nm] |
4,800 |
0.08 |
FRN442M |
20mm |
46mm |
12mm |
212[Nm] |
4,200 |
0.1 |
FRN442Z |
20mm |
46mm |
12mm |
198[Nm] |
4,200 |
0.1 |
FRN453M |
25mm |
58mm |
12mm |
321[Nm] |
3,400 |
0.17 |
FRN453Z |
25mm |
58mm |
12mm |
294[Nm] |
3,400 |
0.17 |
FRN459M |
30mm |
64mm |
12mm |
332[Nm] |
3,000 |
0.2 |
FRN459Z |
30mm |
64mm |
12mm |
353[Nm] |
3,000 |
0.2 |
FRN463M |
35mm |
68mm |
12mm |
427[Nm] |
2,900 |
0.21 |
FRN463Z |
35mm |
68mm |
12mm |
393[Nm] |
2,900 |
0.21 |
FRN470M |
40mm |
75mm |
12mm |
506[Nm] |
2,600 |
0.25 |
FRN470Z |
40mm |
75mm |
12mm |
466[Nm] |
2,600 |
0.25 |
FRN473M |
45mm |
78mm |
12mm |
539[Nm] |
2,500 |
0.26 |
FRN473Z |
45mm |
78mm |
12mm |
496[Nm] |
2,500 |
0.26 |
FE412Z |
4mm |
12mm |
12mm |
4[Nm] |
27,000 |
0.003 |
FE416Z |
8mm |
16mm |
12mm |
16[Nm] |
19,200 |
0.006 |
FE420Z |
12mm |
20mm |
12mm |
35[Nm] |
12,500 |
0.007 |
FE422Z |
14mm |
22mm |
12mm |
53[Nm] |
10,100 |
0.008 |
FE423Z |
15mm |
23mm |
12mm |
62[Nm] |
9,200 |
0.009 |
FE425Z |
17mm |
25mm |
12mm |
72[Nm] |
8,100 |
0.011 |
FE427Z |
19mm |
27mm |
12mm |
83[Nm] |
7,400 |
0.013 |
FE428Z |
20mm |
28mm |
12mm |
93[Nm] |
7,500 |
0.013 |
FE430Z |
22mm |
30mm |
12mm |
107[Nm] |
6,300 |
0.014 |
FE432Z |
24mm |
32mm |
12mm |
117[Nm] |
5,900 |
0.016 |
FE433Z |
25mm |
33mm |
12mm |
128[Nm] |
6,000 |
0.016 |
FE435Z |
27mm |
35mm |
12mm |
143[Nm] |
5,100 |
0.017 |
FE437Z |
29mm |
37mm |
12mm |
154[Nm] |
4,800 |
0.018 |
FE438Z |
30mm |
38mm |
12mm |
166[Nm] |
4,900 |
0.019 |
FE442Z |
34mm |
42mm |
12mm |
198[Nm] |
4,400 |
0.018 |
FE443Z |
35mm |
43mm |
12mm |
207[Nm] |
4,300 |
0.022 |
FE448Z |
40mm |
48mm |
12mm |
248[Nm] |
4,200 |
0.024 |
FE453Z |
45mm |
53mm |
12mm |
293[Nm] |
3,400 |
0.022 |
FE455Z |
47mm |
55mm |
12mm |
313[Nm] |
3,300 |
0.026 |
FE458Z |
50mm |
58mm |
12mm |
344[Nm] |
3,100 |
0.029 |
FE459Z |
51mm |
59mm |
12mm |
353[Nm] |
3,000 |
0.03 |
FE463Z |
55mm |
63mm |
12mm |
393[Nm] |
2,900 |
0.032 |
FE468Z |
60mm |
68mm |
12mm |
444[Nm] |
2,700 |
0.034 |
FE470Z |
62mm |
70mm |
12mm |
465[Nm] |
2,600 |
0.035 |
FE473Z |
65mm |
73mm |
12mm |
495[Nm] |
2,500 |
0.037 |
FE478Z |
70mm |
78mm |
12mm |
548[Nm] |
2,600 |
0.039 |
FE488Z |
80mm |
88mm |
12mm |
657[Nm] |
2,100 |
0.045 |
FE508Z |
100mm |
108mm |
12mm |
889[Nm] |
1,700 |
0.055 |
FE528Z |
120mm |
128mm |
12mm |
1127[Nm] |
1,300 |
0.066 |
FE648Z |
240mm |
248mm |
12mm |
2673[Nm] |
800 |
0.131 |
FE422M |
14mm |
22mm |
12mm |
59[Nm] |
10,100 |
0.011 |
FE423M |
15mm |
23mm |
12mm |
66[Nm] |
9,200 |
0.012 |
FE425M |
17mm |
25mm |
12mm |
79[Nm] |
8,100 |
0.013 |
FE427M |
19mm |
27mm |
12mm |
92[Nm] |
7,400 |
0.014 |
FE428M |
20mm |
28mm |
12mm |
99[Nm] |
7,500 |
0.014 |
FE430M |
22mm |
30mm |
12mm |
114[Nm] |
6,300 |
0.016 |
FE432M |
24mm |
32mm |
12mm |
128[Nm] |
5,900 |
0.016 |
FE433M |
25mm |
33mm |
12mm |
140[Nm] |
6,000 |
0.017 |
FE435M |
27mm |
35mm |
12mm |
153[Nm] |
5,100 |
0.018 |
FE437M |
29mm |
37mm |
12mm |
169[Nm] |
4,800 |
0.019 |
FE438M |
30mm |
38mm |
12mm |
178[Nm] |
4,900 |
0.02 |
FE442M |
34mm |
42mm |
12mm |
213[Nm] |
4,200 |
0.022 |
FE443M |
35mm |
43mm |
12mm |
224[Nm] |
4,300 |
0.023 |
FE448M |
40mm |
48mm |
12mm |
271[Nm] |
4,300 |
0.025 |
FE453M |
45mm |
53mm |
12mm |
321[Nm] |
3,400 |
0.028 |
FE458M |
50mm |
58mm |
12mm |
372[Nm] |
3,400 |
0.031 |
FE459M |
51mm |
59mm |
12mm |
381[Nm] |
3,000 |
0.032 |
FE463M |
55mm |
63mm |
12mm |
426[Nm] |
2,900 |
0.035 |
FE468M |
60mm |
68mm |
12mm |
481[Nm] |
2,700 |
0.036 |
FE470M |
62mm |
70mm |
12mm |
505[Nm] |
2,600 |
0.037 |
FE473M |
65mm |
73mm |
12mm |
538[Nm] |
2,500 |
0.04 |
FE478M |
70mm |
78mm |
12mm |
596[Nm] |
2,600 |
0.043 |
FE488M |
80mm |
88mm |
12mm |
715[Nm] |
2,100 |
0.048 |
FE410Z2 |
2mm |
10mm |
7mm |
0,6 |
52,600 |
0.001 |
FE412Z2 |
4mm |
12mm |
7mm |
2,5 |
40,900 |
0.002 |
FE413Z2 |
5mm |
13mm |
7mm |
4[Nm] |
34,900 |
0.003 |
FE414Z2 |
6mm |
14mm |
7mm |
6[Nm] |
31,200 |
0.003 |
FE416Z2 |
8mm |
16mm |
7mm |
10[Nm] |
27,200 |
0.004 |
FE418Z2 |
10mm |
18mm |
7mm |
16[Nm] |
18,900 |
0.005 |
FE422Z2 |
14mm |
22mm |
7mm |
30[Nm] |
13,200 |
0.006 |
FE423Z2 |
15mm |
23mm |
7mm |
40[Nm] |
13,200 |
0.006 |
FE425Z2 |
17mm |
25mm |
7mm |
43[Nm] |
10,600 |
0.007 |
FE428Z2 |
20mm |
28mm |
7mm |
55[Nm] |
9,700 |
0.008 |
FE433Z2 |
25mm |
33mm |
7mm |
78[Nm] |
7,700 |
0.01 |
FE437Z2 |
29mm |
37mm |
7mm |
97[Nm] |
6,100 |
0.011 |
FE438Z2 |
30mm |
38mm |
7mm |
105[Nm] |
6,400 |
0.011 |
FE442Z2 |
34mm |
42mm |
7mm |
125[Nm] |
5,400 |
0.012 |
FE443Z2 |
35mm |
43mm |
7mm |
131[Nm] |
5,600 |
0.013 |
FE448Z2 |
40mm |
48mm |
7mm |
156[Nm] |
5,500 |
0.014 |
FE453Z2 |
45mm |
53mm |
7mm |
185[Nm] |
4,400 |
0.016 |
FE458Z2 |
50mm |
58mm |
7mm |
216[Nm] |
4,400 |
0.017 |
FE463Z2 |
55mm |
63mm |
7mm |
246[Nm] |
3,700 |
0.019 |
FE468Z2 |
60mm |
68mm |
7mm |
277[Nm] |
3,500 |
0.02 |
FE8038Z16 |
38mm |
55mm |
16mm |
609[Nm] |
** |
0.082 |
FE8038Z19 |
38mm |
55mm |
19mm |
801[Nm] |
** |
0.096 |
FE8040Z16 |
40mm |
57mm |
16mm |
668[Nm] |
** |
0.084 |
FE8040Z19 |
40mm |
57mm |
19mm |
880[Nm] |
** |
0.102 |
FE8044Z16 |
44mm |
61mm |
16mm |
799[Nm] |
** |
0.091 |
FE8044Z19 |
44mm |
61mm |
19mm |
1[Nm] |
** |
0.112 |
FE8049Z16 |
50mm |
66mm |
16mm |
923[Nm] |
** |
0.1 |
FE8049Z19 |
50mm |
66mm |
19mm |
1[Nm] |
** |
0.118 |
FE8050Z16 |
50mm |
67mm |
16mm |
942[Nm] |
** |
0.1 |
FE8050Z25 |
50mm |
67mm |
19mm |
1237[Nm] |
** |
0.123 |
FE8054Z16 |
55mm |
71mm |
16mm |
1080[Nm] |
** |
0.107 |
FE8054Z19 |
55mm |
71mm |
19mm |
1424[Nm] |
** |
0.128 |
FE8054Z25 |
55mm |
71mm |
25mm |
2015[Nm] |
** |
0.172 |
FE8060Z16 |
60mm |
77mm |
16mm |
1243[Nm] |
** |
0.113 |
FE8060Z19 |
60mm |
77mm |
19mm |
1560[Nm] |
** |
0.141 |
FE8060Z25 |
60mm |
77mm |
25mm |
2111[Nm] |
** |
0.188 |
FE8072Z16 |
72mm |
89mm |
16mm |
1740[Nm] |
** |
0.135 |
FE8072Z19 |
72mm |
89mm |
19mm |
2145[Nm] |
** |
0.163 |
FE8072Z25 |
72mm |
89mm |
25mm |
2918[Nm] |
** |
0.22 |
FE8079Z25 |
80mm |
96mm |
25mm |
3295[Nm] |
** |
0.227 |
FE8080Z16 |
80mm |
97mm |
16mm |
1848[Nm] |
** |
0.141 |
FE8080Z19 |
80mm |
97mm |
19mm |
2278[Nm] |
** |
0.176 |
FE8080Z25 |
80mm |
97mm |
25mm |
3101[Nm] |
** |
0.235 |
FE8083Z25 |
83mm |
100mm |
25mm |
3640[Nm] |
** |
0.245 |
FE8100Z16 |
100mm |
117mm |
16mm |
2632[Nm] |
** |
0.188 |
FE8100Z19 |
100mm |
117mm |
19mm |
3303[Nm] |
** |
0.228 |
FE8100Z25 |
100mm |
117mm |
25mm |
4535[Nm] |
** |
0.306 |
FE8103Z16 |
103mm |
120mm |
16mm |
2887[Nm] |
** |
0.184 |
FE8103Z19 |
103mm |
120mm |
19mm |
3582[Nm] |
** |
0.29 |
FE8103Z25 |
103mm |
120mm |
25mm |
4920[Nm] |
** |
0.3 |
FES8123Z25 |
123mm |
140mm |
25mm |
6600[Nm] |
** |
0.37 |
FE8123Z25 |
124mm |
141mm |
25mm |
6604[Nm] |
** |
0.37 |
FE8126Z25 |
126mm |
143mm |
25mm |
6744[Nm] |
** |
0.375 |
FE8140Z25 |
140mm |
157mm |
25mm |
7388[Nm] |
** |
0.41 |
FE8150Z25 |
150mm |
167mm |
25mm |
8272[Nm] |
** |
0.44 |
FE8160Z25 |
160mm |
177mm |
25mm |
9096[Nm] |
** |
0.47 |
FE8180Z25 |
180mm |
197mm |
25mm |
10463[Nm] |
** |
0.52 |
FE8220Z25 |
220mm |
237mm |
25mm |
14060[Nm] |
** |
0.64 |
RL412-4 |
4mm |
12mm |
6mm |
3040[Nm] |
55,000 |
0.001 |
RL414-4 |
6mm |
14mm |
6mm |
3575[Nm] |
50,000 |
0.001 |
RL416-4 |
8mm |
16mm |
6mm |
3895[Nm] |
36,000 |
0.001 |
RL418-4 |
10mm |
18mm |
6mm |
5212[Nm] |
30,000 |
0.001 |
RL422-4 |
14mm |
22mm |
6mm |
6013[Nm] |
25,000 |
0.001 |
RL423-4 |
15mm |
23mm |
6mm |
6034[Nm] |
24,000 |
0.001 |
RL425-4 |
17mm |
25mm |
6mm |
7157[Nm] |
21,000 |
0.001 |
RL427-4 |
19mm |
27mm |
6mm |
7679[Nm] |
20,000 |
0.001 |
RL428-4 |
20mm |
28mm |
6mm |
7679[Nm] |
19,000 |
0.001 |
RL430-4 |
22mm |
30mm |
6mm |
8150[Nm] |
17,000 |
0.001 |
RL432-4 |
24mm |
32mm |
6mm |
8104[Nm] |
16,000 |
0.001 |
RL433-4 |
25mm |
33mm |
6mm |
8104[Nm] |
15,000 |
0.001 |
RL437-4 |
29mm |
37mm |
6mm |
8962[Nm] |
14,000 |
0.001 |
RL438-4 |
30mm |
38mm |
6mm |
8962[Nm] |
13,000 |
0.001 |
RL442-4 |
34mm |
42mm |
6mm |
10247[Nm] |
12,000 |
0.001 |
RL443-4 |
35mm |
43mm |
6mm |
10103[Nm] |
12,000 |
0.001 |
RL448-4 |
40mm |
48mm |
6mm |
11642[Nm] |
10,000 |
0.001 |
RL453-4 |
45mm |
53mm |
6mm |
11417[Nm] |
9,000 |
0.001 |
RL455-4 |
47mm |
55mm |
6mm |
11417[Nm] |
8,800 |
0.001 |
RL458-4 |
50mm |
58mm |
6mm |
11922[Nm] |
8,500 |
0.001 |
RL459-4 |
51mm |
59mm |
6mm |
12691[Nm] |
8,000 |
0.001 |
RL463-4 |
55mm |
63mm |
6mm |
13070[Nm] |
7,500 |
0.001 |
RL468-4 |
60mm |
68mm |
6mm |
12690[Nm] |
7,100 |
0.001 |
RL470-4 |
62mm |
70mm |
6mm |
14128[Nm] |
7,000 |
0.001 |
RL473-4 |
65mm |
73mm |
6mm |
14128[Nm] |
6,500 |
0.001 |
RL478-4 |
70mm |
78mm |
6mm |
13614[Nm] |
6,000 |
0.001 |
RL488-4 |
80mm |
88mm |
6mm |
14954[Nm] |
5,300 |
0.001 | |
