BEARING

NO.

DIMENSIONS IN INCHES

a°

Misalign.

 Angle

Radial

Static

Limit

Load

Capacity

Lbs.

Approx.

 Brg.

 Wt.

Lbs.

B

+ .0015

- .0005

D

+ .0000

- .0007

H

± .005

W

± .005

O

Flat Dia

 Ref.

M

Chamfer

 Ref.

Ball

Dia

Ref.

COM-3

.1900

.5625

.218

.281

.293

.015

.406

11

3,250

.01

COM-4

.2500

.6562

.250

.343

.364

.022

.500

13.5

4,950

.02

COM-5

.3125

.7500

.281

.375

.419

.032

.562

12

6,475

.03

COM-6

.3750

.8125

.312

.406

.516

.032

.656

10

8,400

.04

COM-7

.4375

.9062

.343

.437

.530

.032

.687

8

9,453

.05

COM-8

.5000

1.0000

.390

.500

.640

.032

.813

9.5

13,250

.07

COM-9

.5625

1.0937

.437

.562

.710

.032

.906

9.5

16,630

.09

COM-10

.6250

1.1875

.500

.625

.780

.032

1.000

8.5

21,280

.11

COM-12

.7500

1.4375

.593

.750

.920

.044

1.187

9

31,920

.20

COM-14

.8750

1.5625

.703

.875

.980

.044

1.312

9.5

41,960

.26

*COM-16

1.0000

1.7500

.797

1.000

1.118

.044

1.500

10

55,200

.39

*HCOM-16

1.0000

2.0000

.781

1.000

1.360

.032

1.687

9

70,820

.55

*HCOM-19

1.1875

2.3750

.937

1.187

1.610

.032

2.000

8.5

100,730

.90

*HCOM-20

1.2500

2.3750

.937

1.187

1.610

.032

2.000

8.5

100,730

.90

*HCOM-24

1.5000

2.7500

1.094

1.375

1.860

.032

2.312

8.5

135,950

1.36

*HCOM-28

1.7500

3.1250

1.250

1.562

2.110

.044

2.625

8

176,370

1.95

*HCOM-32

2.0000

3.5000

1.375

1.750

2.360

.044

2.937

8.5

217,060

2.65

BEARING

NO.

DIMENSIONS IN MILLIMETERS

a°

Misalign.

 Angle

Radial

Static

Limit

Load

Capacity

 Newtons

Approx.

 Brg.

Wt.

Grams

B

+ .038

- .013

D

+ .000

- .018

H

± .13

W

± .13

O

Flat Dia

 Ref.

M

Chamfer

Ref.

Ball Dia

Ref.

COM-3

4.826

14.29

5.54

7.14

7.44

.38

10.31

11

14,464

6

COM-4

6.350

16.67

6.35

8.71

9.25

.56

12.70

13.5

22,015

10

COM-5

7.938

19.05

7.14

9.53

10.64

.81

14.27

12

28,800

14

COM-6

9.525

20.64

7.92

10.31

13.11

.81

16.66

10

37,361

17

COM-7

11.113

23.02

8.71

11.10

13.46

.81

17.45

8

42,048

21

COM-8

12.700

25.40

9.91

12.70

16.26

.81

20.65

9.5

58,934

29

COM-9

14.288

27.78

11.10

14.27

18.03

.81

23.01

9.5

73,967

39

COM-10

15.875

30.16

12.70

15.88

19.81

.81

25.40

8.5

94,658

50

COM-12

19.050

36.51

15.06

19.05

23.37

1.12

30.15

9

141,982

93

COM-14

22.225

39.69

17.86

22.23

24.89

1.12

33.32

9.5

186,639

119

*COM-16

25.400

44.45

20.24

25.40

28.40

1.12

38.10

10

245,534

175

*HCOM-16

25.400

50.80

19.84

25.40

34.54

.81

42.85

9

315,010

251

*HCOM-19

30.163

60.33

23.80

30.15

40.89

.81

50.80

8.5

448,049

406

*HCOM-20

31.750

60.33

23.80

30.15

40.89

.81

50.80

8.5

448,049

406

*HCOM-24

38.100

69.85

27.79

34.93

47.24

.81

58.72

8.5

604,710

616

*HCOM-28

44.450

79.38

31.75

39.67

53.59

1.12

66.68

8

784,495

884

*HCOM-32

50.800

88.90

34.93

44.45

59.94

1.12

74.60

8.5

965,485

1,198
