Bearing

Shaft Size Inch

TRIDENT Seal

Labyrinth Seal

Non-Expansion

Expansion

Non-Expansion

Expansion

Part No.

Part Name

Part No.

Part Name

Part No.

Part Name

Part No.

Part Name

22208

1-3/8

070644

FC-S2-106R

070671

FC-S2-106RE

070698

FC-S2-106L

070725

FC-S2-106LE

1-7/16

070645

FC-S2-107R

070672

FC-S2-107RE

070699

FC-S2-107L

070726

FC-S2-107LE

1-1/2

070646

FC-S2-108R

070673

FC-S2-108RE

070700

FC-S2-108L

070727

FC-S2-108LE

22209

1-11/16 1-3/4

070648 070649

FC-S2-111R  FC-S2-112R

070675 070676

FC-S2-111RE  FC-S2-112RE

070702 070703

FC-S2-111L  FC-S2-112L

070729 070730

FC-S2-111LE  FC-S2-112LE

22210

1-15/16 2

070650 070651

FC-S2-115R  FC-S2-200R

070677 070678

FC-S2-115RE  FC-S2-200RE

070704 070705

FC-S2-115L  FC-S2-200L

070731 070732

FC-S2-115LE  FC-S2-200LE

22211

2-3/16

070652

FC-S2-203R

070679

FC-S2-203RE

070706

FC-S2-203L

070733

FC-S2-203LE

22213

2-7/16

070654

FC-S2-207R

070681

FC-S2-207RE

070708

FC-S2-207L

070735

FC-S2-207LE

22215

2-11/16

070656

FC-S2-211R

070683

FC-S2-211RE

070710

FC-S2-211L

070737

FC-S2-211LE

2-15/16

070657

FC-S2-215R

070684

FC-S2-215RE

070711

FC-S2-215L

070738

FC-S2-215LE

3

070658

FC-S2-300R

070685

FC-S2-300RE

070712

FC-S2-300L

070739

FC-S2-300LE

22218

3-7/16

070660

FC-S2-307R

070687

FC-S2-307RE

070714

FC-S2-307L

070741

FC-S2-307LE

22220

3-15/16

070662

FC-S2-315R

070689

FC-S2-315RE

070716

FC-S2-315L

070743

FC-S2-315LE

22222

4-7/16

070664

FC-S2-407R

070691

FC-S2-407RE

070718

FC-S2-407L

070745

FC-S2-407LE

22226

4-15/16

070666

FC-S2-415R

070693

FC-S2-415RE

070720

FC-S2-415L

070747

FC-S2-415LE

SHAFT SIZE

A

B

C

D

DD

E

F BOLT DIA.

G

H

K

L

M

N

P

Q

X TOTAL EXP..

1-3/8 1-7/16 1-1/2

2-17/32

5-1/4

1-27/32

3-3/32

4-3/8

3/4

3/8

1-5/16

1/2

3. 625

2-3/4

3/8-16

2-17/32

1-7/32

1-7/32

3/16

1-11/16 1-3/4

2-43/64

6-1/8

1-29/32

3-5/8

5-1/8

7/8

7/16

1-29/64

1/2

4. 250

3-3/16

7/16-14

2-23/32

1-7/32

1-17/64

1/4

1-15/16 2

2-27/32

6-3/8

2

3-51/64

5-3/8

7/8

7/16

1-19/32

9/16

4. 500

3-7/16

7/16-14

2-55/64

1-1/4

1-17/64

1/4

2-3/16

2-15/16

7-1/8

2-3/16

4-1/4

6

1

1/2

1-9/16

9/16

5. 000

3-3/4

1/2-13

2-63/64

1-3/8

1-27/64

1/4

2-7/16

3-13/64

7-5/8

2-1/2

4-19/32

6-1/2

1

1/2

1-41/64

5/8

5. 500

4-1/16

1/2-13

3-13/64

1-9/16

1-9/16

1/4

2-11/16 2-15/16 3

3-19/32

8-3/4

2-5/8

5-19/64

7-1/2

1-1/4

5/8

2-1/32

3/4

6. 375

4-45/64

5/8-11

3-41/64

1-9/16

1-5/8

1/4

3-7/16

4

10-1/4

3

6-3/32

8-5/8

1-17/64

3/4

2-23/64

15/16

7. 375

5-1/2

3/4-10

3-7/8

1-41/64

1-33/64

1/4

3-15/16

4-15/32

10-7/8

3-1/2

6-5/8

9-3/8

1-15/32

3/4

2-21/32

1-1/8

8. 125

6

3/4-10

4-9/16

1-13/16

1-29/32

5/16

4-7/16

6-17/32

13-37/64

4

** 5-7/8

11-3/4

1-29/64

3/4**

3-17/32

1

10. 250

6-29/64

3/4-10

5-1/2

3

1-63/64

3/8

4-15/16

6-29/32

14-27/32

4-3/8

** 6-3/8

12-3/4

1-45/64

7/8**

3-7/16

1-1/4

11. 000

7-29/64

7/8-9

5-55/64

3-15/32

2-27/64

3/8
