Series

Shaft Size

Complete Unit Part No.   Description

Unit without Adapter Sleeve & Lock Nut Part No.    Description

Adapter Sleeve & Lock Nut Assembly Part No.      Description

203

1/2

@

F4B-GTAH-008

@

F4B-GTAH-03

129902

AN-GT-03-008

5/8

@

F4B-GTAH-010

129903

AN-GT-03-010

17mm

@

F4B-GTAH-17M

129942

AN-GT-03-17M

204

3/4 20mm

@ @

F4B-GTAH-012 F4B-GTAH-20M

@

F4B-GTAH-04

129904 129943

AN-GT-04-012 AN-GT-04-20M

205

7/8

@

F4B-GTAH-014

129476

F4B-GTAH-05

129905

AN-GT-05-014

15/16

@

F4B-GTAH-015

129906

AN-GT-05-015

1

129659

F4B-GTAH-100

129907

AN-GT-05-100

25mm

@

F4B-GTAH-25M

129944

AN-GT-05-25M

206

1-1/8

@

F4B-GTAH-102

129477

F4B-GTAH-06

129908

AN-GT-06-102

1-3/16

129660

F4B-GTAH-103

129909

AN-GT-06-103

1-1/4

@

F4B-GTAH-104S

129910

AN-GT-06-104S

30mm

@

F4B-GTAH-30M

129945

AN-GT-06-30M

207

1-1/4

@

F4B-GTAH-104

129478

F4B-GTAH-07

129911

AN-GT-07-104

1-3/8

@

F4B-GTAH-106

129912

AN-GT-07-106

1-7/16

129661

F4B-GTAH-107

129913

AN-GT-07-107

35mm

@

F4B-GTAH-35M

129946

AN-GT-07-35M

Series

Shaft Size

Weight lbskg

A

B

C#

D

F Bolt Dia.

H

J

L

N

Z

203

1/2

1.4

1-19/64

3

1-27/64

2-1/8

3/8

7/16

39/64

1-13/32

1-11/16

1-29/64

5/8

1.3

17mm

0.6

32.9

76.2

36.1

54.0

M10

11.1

15.5

35.7

42.9

36.9

204

3/4 20mm

1.7 0.8

1-15/32 37.3

3-3/8 85.7

1-39/64 40.9

2-1/2 63.5

3/8 M10

7/16 11.1

5/8 15.9

1-1/2 38.1

1-15/16 49.2

1-43/64 42.5

205

7/8

2.2

1-29/64

3-3/4

1-35/64

2-3/4

7/16

1/2

19/32

1-51/64

2-1/16

1-39/64

15/16

2.2

1

2.2

25mm

1.0

36.9

95.3

39.3

69.9

M10

12.7

15.1

45.6

52.4

40.9

206

1-1/8

3.8

1-39/64

4-1/4

1-45/64

3-1/4

7/16

1/2

19/32

2-5/64

2-3/16

1-3/4

1-3/16

3.7

1-1/4

3.7

30mm

1.7

40.9

108.0

43.3

82.6

M10

12.7

15.1

52.8

55.6

44.5

207

1-1/4

4.4

1-5/8

4-3/4

1-49/64

3-5/8

1/2

9/16

17/32

2-3/8

2-7/16

1-55/64

1-3/8

4.4

1-7/16

4.3

35mm

2.0

41.3

120.7

44.8

92.1

M12

14.3

13.5

60.3

61.9

47.2
