ROD END NO.

DIMENSIONS IN INCHES

a° Misalign.

 Angle

Ultimate Radial

Static Load

Capacity Lbs.

Approx.

Brg. Wt.

Lbs.

Right

Hand

Left

Hand

B

+ .0015

- .0005

W

+ .000

- .005

H

± .005

A

± .015

D

± .010

Ball Dia. Ref.

C

+ .062

- .031

Thread

UNF-3A

BM-3

BB-3

.1900

.312

.250

1.250

.625

.437

.750

10-32

13

1,169

.03

BM-4

BB-4

.2500

.375

.281

1.562

.750

.500

1.000

1/4-28

16

2,158

.04

BM-5

BB-5

.3125

.437

.344

1.875

.875

.625

1.250

5/16-24

14

2,784

.07

BM-6

BB-6

.3750

.500

.406

1.938

1.000

.719

1.250

3/8-24

12

3,915

.11

BM-7

BB-7

.4375

.562

.437

2.125

1.125

.812

1.375

7/16-20

14

4,218

.16

BM-8

BB-8

.5000

.625

.500

2.438

1.312

.937

1.500

1/2-20

12

6,660

.25

BM-10

BB-10

.6250

.750

.562

2.625

1.500

1.125

1.625

5/8-18

16

7,364

.38

BM-12

BB-12

.7500

.875

.687

2.875

1.750

1.312

1.750

3/4-16

14

11,518

.60
