BRG. NO.

OUTSIDE

ROLLER DIA.

(OD)

POINT

DIA.

(V)

WIDTH

(W)

GROOVE

CENTER

(C)

MIN.

THREAD LENGTH

(TL)

FINE

THREADS

STUD

LENGTH

(SL)

ECCENTRIC DIA. (BD)

±.001

ECCENTRIC

LENGTH (G)

+.000

-.010

ECCENTRIC

(ECC)

HEX

SOCKET

(H)

SHOULDER

DIAMETER

(E)

RADIAL

BASIC DYNAMIC RATING (LBS)

DYNAMIC

THRUST LOAD RATING (LBS)

MAX.

STATIC CAPACITY

(LBS)

VCFE-2 1/2

2 1/2

1 1/2

1 5/16

11/16

.895

3/4-16

1 3/4

1.000

.855

.030

1/4

1 1/4

2520

1320

1370

VCFE-3 1/2

3 1/2

2 1/4

1 11/16

7/8

1.020

7/8-14

2

1.187

.980

.030

3/8

1 1/2

3490

1830

2000

VCFE-4 1/2

4 1/2

3

2

1

1.270

1 1/4-12

2 1/2

1.750

1.230

.060

7/16

1 3/4

14300

5790

16000
