| REP4ML6、REP5M6-2、REP5M7、REP8M10 |
|
上海川代轴承机械有限公司 新闻动态 2025-12-9
|
|
|
|
Bearing Number |
MS 21151
Dash No. |
Bore B
+0.0000,-.0003
+0.000,-.008 |
Outside Diameter D
±.010
±.25 |
Widths
W H
+0.000,-.005 ±.010
+0.00,-.13 ±.25 |
A
Approx. |
F
±.010
±.25 |
L (1)
±.031
±.79 |
M UNJF-3A
Threads Per AS8879 |
Wt.
Approx. |
Radial Limit Load Rating |
|
|
in. |
mm |
in. |
mm |
in. |
mm |
in. |
mm |
in. |
mm |
in. |
mm |
in. |
mm |
|
lbs. |
kg |
lbf. |
N |
|
REP3MR3 |
-2 |
0.1900 |
4.826 |
0.781 |
19.84 |
0.437 |
11.10 |
0.328 |
8.33 |
0.281 |
7.14 |
1.375 |
34.92 |
0.750 |
19.05 |
10-32RH |
0.04 |
0.018 |
1000 |
4400 |
|
REP3ML3 |
-1 |
0.1900 |
4.826 |
0.781 |
19.84 |
0.437 |
11.10 |
0.328 |
8.33 |
0.281 |
7.14 |
1.375 |
34.92 |
0.750 |
19.05 |
10-32LH |
0.04 |
0.018 |
1000 |
4400 |
|
REP3M4-6 |
-7 |
0.1900 |
4.826 |
0.781 |
19.84 |
0.437 |
11.10 |
0.328 |
8.33 |
0.281 |
7.14 |
1.562 |
39.67 |
1.000 |
25.40 |
1⁄4-28RH |
0.05 |
0.023 |
1000 |
4400 |
|
REP3MS4-6(2) |
-7C |
0.1900 |
4.826 |
0.781 |
19.84 |
0.437 |
11.10 |
0.328 |
8.33 |
0.281 |
7.14 |
1.562 |
39.67 |
1.000 |
25.40 |
1⁄4-28RH |
0.05 |
0.023 |
1000 |
4400 |
|
REP3M6-2N |
-4 |
0.1900 |
4.826 |
0.781 |
19.84 |
0.437 |
11.10 |
0.328 |
8.33 |
0.281 |
7.14 |
1.375 |
34.92 |
0.750 |
19.05 |
3⁄8-24RH |
0.05 |
0.023 |
1000 |
4400 |
|
REP3MS6-2N(2) |
-4C |
0.1900 |
4.826 |
0.781 |
19.84 |
0.437 |
11.10 |
0.328 |
8.33 |
0.281 |
7.14 |
1.375 |
34.92 |
0.750 |
19.05 |
3⁄8-24RH |
0.05 |
0.023 |
1000 |
4400 |
|
REP3ML6-2N |
-5 |
0.1900 |
4.826 |
0.781 |
19.84 |
0.437 |
11.10 |
0.328 |
8.33 |
0.281 |
7.14 |
1.375 |
34.92 |
0.750 |
19.05 |
3⁄8-24LH |
0.05 |
0.023 |
1000 |
4400 |
|
REP3MLS6(2) |
-5C |
0.1900 |
4.826 |
0.781 |
19.84 |
0.437 |
11.10 |
0.328 |
8.33 |
0.281 |
7.14 |
1.375 |
34.92 |
0.750 |
19.05 |
3⁄8-24LH |
0.05 |
0.023 |
1000 |
4400 |
|
RAP3M4-2 |
-6 |
0.1900 |
4.826 |
0.781 |
19.84 |
0.500 |
12.70 |
0.438 |
11.13 |
0.312 |
7.92 |
1.812 |
46.02 |
0.938 |
23.83 |
1⁄4-28RH |
0.10 |
0.045 |
1000 |
4400 |
|
RAP3MS4-2(2) |
-6C |
0.1900 |
4.826 |
0.781 |
19.84 |
0.500 |
12.70 |
0.438 |
11.13 |
0.312 |
7.92 |
1.812 |
46.02 |
0.938 |
23.83 |
1⁄4-28RH |
0.10 |
0.045 |
1000 |
4400 |
|
REP3M6A |
-3 |
0.1900 |
4.826 |
0.969 |
24.61 |
0.500 |
12.70 |
0.407(4) |
10.34 |
0.304 |
7.72 |
2.031 |
51.59 |
1.313 |
33.35 |
3⁄8-24RH |
0.115 |
0.052 |
1200 |
5300 |
|
REP3MS6A(2) |
-3C |
0.1900 |
4.826 |
0.969 |
24.61 |
0.500 |
12.70 |
0.407(4) |
10.34 |
0.304 |
7.72 |
2.031 |
51.59 |
1.313 |
33.35 |
3⁄8-24RH |
0.115 |
0.052 |
1200 |
5300 |
|
REP4M6 |
-8 |
0.2500 |
6.350 |
0.938 |
23.83 |
0.593 |
15.06 |
0.438 |
11.13 |
0.345 |
8.76 |
1.875 |
47.62 |
1.125 |
28.58 |
3⁄8-24RH |
0.10 |
0.045 |
1720 |
7650 |
|
REP4M6-4(2) |
-8C |
0.2500 |
6.350 |
0.938 |
23.83 |
0.593 |
15.06 |
0.438 |
11.13 |
0.345 |
8.76 |
1.875 |
47.62 |
1.125 |
28.58 |
3⁄8-24RH |
0.10 |
0.045 |
1720 |
7650 |
|
REP4ML6 |
-9 |
0.2500 |
6.350 |
0.938 |
23.83 |
0.593 |
15.06 |
0.438 |
11.13 |
0.345 |
8.76 |
1.875 |
47.62 |
1.125 |
28.58 |
3⁄8-24LH |
0.10 |
0.045 |
1720 |
7650 |
|
REP4ML6-4(2) |
-9C |
0.2500 |
6.350 |
0.938 |
23.83 |
0.593 |
15.06 |
0.438 |
11.13 |
0.345 |
8.76 |
1.875 |
47.62 |
1.125 |
28.58 |
3⁄8-24LH |
0.10 |
0.045 |
1720 |
7650 |
|
REP5M6 |
-10 |
0.3125 |
7.938 |
1.250 |
31.75 |
0.870 |
22.10 |
0.656 |
16.66 |
0.506 |
12.85 |
2.438 |
61.93 |
1.563 |
39.70 |
3⁄8-24RH |
0.24 |
0.109 |
2920 |
12900 |
|
REP5M6-2(2) |
-10C |
0.3125 |
7.938 |
1.250 |
31.75 |
0.870 |
22.10 |
0.656 |
16.66 |
0.506 |
12.85 |
2.438 |
61.93 |
1.563 |
39.70 |
3⁄8-24RH |
0.24 |
0.109 |
2920 |
12900 |
|
REP5M7 |
-11 |
0.3125 |
7.938 |
1.250 |
31.75 |
0.870 |
22.10 |
0.656 |
16.66 |
0.506 |
12.85 |
2.438 |
61.93 |
1.563 |
39.70 |
7⁄16-20RH |
0.24 |
0.109 |
2920 |
12900 |
|
REP5MS7(2) |
-11C |
0.3125 |
7.938 |
1.250 |
31.75 |
0.870 |
22.10 |
0.656 |
16.66 |
0.506 |
12.85 |
2.438 |
61.93 |
1.563 |
39.70 |
7⁄16-20RH |
0.24 |
0.109 |
2920 |
12900 |
|
REP5M10 |
-12 |
0.3125 |
7.938 |
1.250 |
31.75 |
0.870 |
22.10 |
0.656 |
16.66 |
0.506 |
12.85 |
2.438 |
61.93 |
1.563 |
39.70 |
5⁄8-18RH |
0.24 |
0.109 |
2920 |
12900 |
|
REP5MS10(2) |
-12C |
0.3125 |
7.938 |
1.250 |
31.75 |
0.870 |
22.10 |
0.656 |
16.66 |
0.506 |
12.85 |
2.438 |
61.93 |
1.563 |
39.70 |
5⁄8-18RH |
0.24 |
0.109 |
2920 |
12900 |
|
REP8M10(3) |
- |
0.5000 |
12.700 |
1.875 |
47.62 |
1.000 |
25.40 |
0.844 |
21.44 |
0.688 |
17.48 |
3.031 |
76.99 |
1.750 |
44.45 |
5⁄8-18RH |
0.55 |
0.249 |
6900 |
30500 |
|
RAP10M10 |
-13 |
0.6250 |
15.875 |
2.000 |
50.80 |
1.125 |
28.58 |
0.938 |
23.83 |
0.875 |
22.22 |
2.750 |
69.85 |
1.500 |
38.10 |
5⁄8-18RH |
0.71 |
0.322 |
7090 |
31500 |
|
RAP10MS10(2) |
-13C |
0.6250 |
15.875 |
2.000 |
50.80 |
1.125 |
28.58 |
0.938 |
23.83 |
0.875 |
22.22 |
2.750 |
69.85 |
1.500 |
38.10 |
5⁄8-18RH |
0.71 |
0.322 |
7090 |
31500 | |
REP4ML6、REP5M6-2、REP5M7、REP8M10现货供应，如有需要请及时联系我们。上海川代轴承机械有限公司同时销售
