Shaft

Diameter

Part Number

B

Distance

Between

Bolt Holes

L

Mounting

Surface to

Collar Face

A

D

F

Bolts

G

H

J

M

N

P

Approx.

 Weight

1/2

FX3CL2B08N*■

3

1 1/4

2 1/8

1 3/32

3/8

5/32

1/2

1 25/32

1 5/8

3 7/8

1/4

0.90

5/8

FX3CL210N*■

11/16

FX3CL211N*■

3/4

FX3CL212N*■

3 17/32

1 9/16

2 7/16

1 11/32

3/8

13/64

9/16

2 1/16

1 59/64

4 13/32

3/8

1.20

20.00

FX3CL2M20N*■

89.69

39.90

61.90

34.04

10.00

5.20

14.30

52.30

48.77

111.90

9.53

0.54

7/8

FX3CL214N*Δ■

3 57/64

1 17/32

2 11/16

1 3/8

7/16

3/16

19/32

2 1/16

2 5/64

4 29/32

3/8

1.60

15/16

FX3CL215N*Δ■

1

FX3CL216N*Δ■

25.00

FX3CL2M25N*Δ■

98.82

38.90

68.30

34.80

10.00

4.80

15.10

52.30

52.83

124.60

9.53

0.72

1

FX3CL2B16N*Δ■

4 19/32

1 47/64

3 3/16

1 9/16

7/16

11/64

19/32

2 1/4

2 15/32

5 19/32

27/64

2.40

1 1/8

FX3CL218N*Δ■

1 3/16

FX3CL219N*Δ■

1 1/4

FX3CL2E20N*Δ■

30.00

FX3CL2M30N* Δ■

116.68

43.90

81.00

39.62

10.00

4.40

15.10

57.20

62.48

142.10

10.72

1.08

1 3/16

FX3CL2B19N*Δ■

5 1/8

1 29/32

3 5/8

1 3/4

1/2

5/32

5/8

2 25/64

2 7/8

6 1/8

1/2

3.00

1 1/4

FX3CL220N*Δ■

1 3/8

FX3CL222N*Δ■

1 7/16

FX3CL223N*Δ■

35.00

FX3CL2M35N*Δ■

130.18

48.30

92.10

44.45

12.00

4.00

15.90

60.70

73.15

155.60

12.70

1.35

1 7/16

FX3CL2B23N*Δ■

5 21/32

2 1/8

4

1 15/16

1/2

11/64

5/8

2 37/64

3 3/64

6 25/32

35/64

4.20

1 1/2

FX3CL224N*Δ■

1 5/8

FX3CL2E26N*Δ■

40.00

FX3CL2M40N*Δ■

143.67

53.90

101.60

49.28

12.00

4.40

15.90

65.50

77.47

172.20

13.72

1.90

1 1/2

FX3CL2B24N*Δ■

5 27/32

2 1/8

4 1/4

1 61/64

1/2

7/64

5/8

2 19/32

3 17/64

7 3/32

33/64

5.10

1 5/8

FX3CL226N*Δ■

1 11/16

FX3CL227N*Δ■

1 3/4

FX3CL228N*Δ■

45.00

FX3CL2M45N*Δ■

148.30

53.90

108.00

49.53

12.00

2.80

15.90

65.80

82.80

180.20

13.21

2.30

1 11/16

FX3CL2B27N*Δ■

6 3/16

2 7/16

4 9/16

2 5/64

9/16

19/64

3/4

2 59/64

3 5/8

7 7/16

39/64

6.30

1 3/4

FX3CL2B28N*Δ■

1 7/8

FX3CL230N*Δ■

1 15/16

FX3CL231N*Δ■
