Shaft

Diameter

Part Number

A

Base to

Centerline Height

B

Distance

Between

Bolt Holes

C

D

E

F

Bolts

H

L

M

S

U

W

Approx.

 Weight

1/2

PL3Y2B08N *■

1 1/16

3 1/2

4 5/8

1 15/32

1 5/16

3/8

3/8

2 7/32

1 1/8

3/4

59/64

1 13/64

1.00

5/8

PL3Y210N *■

11/16

PL3Y211N *■

3/4

PL3Y212N *■

1 1/4

3 7/8

5 1/8

1 23/32

1 7/16

3/8

7/16

2 17/32

1 5/16

3/4

1 3/64

1 19/64

1.70

7/8

PL3Y214N *Δ■

1 5/16

4

5 3/8

1 3/4

1 21/64

3/8

7/16

2 3/4

1 1/2

3/4

1 1/16

1 9/32

1.90

15/16

PL3Y215N *Δ■

1

PL3Y216N *Δ■

1 1/8

PL3Y218N *Δ■

1 9/16

4 5/8

6 5/16

1 29/32

1 5/8

1/2

9/16

3 3/16

1 3/4

15/16

1 3/16

1 29/64

2.60

1 3/16

PL3Y219N *Δ■

1 1/4

PL3Y2E20N *Δ■

1 1/4

PL3Y220N *Δ■

1 13/16

4 15/16

6 3/8

2 1/64

1 3/4

1/2

3/4

3 5/8

2 3/16

7/8

1 9/32

1 35/64

3.80

1 3/8

PL3Y222N *Δ■

1 7/16

PL3Y223N *Δ■

1 1/2

PL3Y224N *Δ■

1 15/16

5 3/8

7 1/16

2 7/32

1 7/8

1/2

47/64

3 15/16

2 3/8

15/16

1 3/8

1 41/64

4.80

1 5/8

PL3Y226N *Δ■

2 1/16

5 11/16

7 1/4

2 7/32

2

1/2

3/4

4 1/4

2 1/2

1

1 3/8

1 21/32

5.50

1 11/16

PL3Y227N *Δ■

1 3/4

PL3Y228N *Δ■

1 15/16

PL3Y231N *Δ■

2 3/16

6 3/16

7 7/8

2 15/32

2 1/8

5/8

13/16

4 1/2

2 3/4

15/16

1 1/2

1 25/32

6.20

2

PL3Y2E32N *Δ■

2

PL3Y232N *Δ■

2 7/16

6 29/32

8 7/8

2 13/16

2 5/16

5/8

15/16

4 15/16

3

1 7/32

1 23/32

2 1/64

8.00

2 3/16

PL3Y235N *Δ■

2 1/4

PL3Y236N *Δ■

2 11/16

7 1/2

9 1/2

3 1/16

2 1/2

5/8

1 1/8

5 3/8

3 5/16

1 1/16

1 27/32

2 7/64

11.60

2 3/8

PL3Y238N *Δ■

2 7/16

PL3Y239N *Δ■
