内径

Expansion

Fixed

A

Base to

Centerline Height

B Min.

Distance

Between Bolt Holes

B Max.

Distance

Between Bolt Holes

G

Bolt Hole

Spacing (Width)

C

D

E

F

Bolts

H

L

M

N

P

Approx. Weight

Part Number

Part Number

2 7/16

ZEPS3207F

ZEP3207F

2 3/4

6 15/16

8 3/4

1 7/8

10 1/2

3 21/32

3 5/8

5/8

1 5/8

5 1/2

3 9/16

2 29/32

1 1/64

18.50

2 1/2

ZEPS3208F

ZEP3208F

18.20

2 11/16

ZEPS3211F

ZEP3211F

3 1/8

7 13/16

9 7/8

2 1/8

11 13/16

4 13/64

4 1/4

5/8

1 7/8

6 5/16

4 1/16

3 3/8

1 1/64

28.70

2 15/16

ZEPS3215F

ZEP3215F

27.70

3 7/16

ZEPS3307F

ZEP3307F

3 3/4

9 5/16

11 5/16

2 3/8

13 13/16

4 37/64

4 3/4

3/4

2 1/4

7 1/2

4 15/16

3 31/32

1 9/64

43.60

3 1/2

ZEPS3308F

ZEP3308F

42.70

3 15/16

ZEPS3315F

ZEP3315F

4 1/4

12

13

2 1/4

15 1/4

5 3/16

4 1/2

3/4

2 5/8

8 5/8

5 5/8

4 9/16

1 1/16

61.00
