型號

B

W

O

H

D

F

A

Thread

旋角

球徑
Ball Dia.
Ø

徑向荷重
Radial S.

load
(kgf)

重量
Weight

 (g)

Model No.

H7

+0 -0.1

＊

+0 -0.1

＊

＊

+2 -0

S

α

POS 5 R/L

5

8

7.7

6

17

35

22

5x0.8

13

11.11

340

14

POS 6 R/L

6

9

8.9

6.7

19

38

24

6x1.0

13

12.70

480

21

POS 8 RF/LF
POS 8 R/L

8

12

10.4

9

23.5

45

26

8x1.0
8x1.25

13

15.88

680

41

POS 10 RF/LF
POS 10 R/L

10

14

12.9

10.5

27

50

30

10x1.25
10x1.5

13

19.05

1,070

65

POS 12 RF/LF
POS 12 R/L

12

16

15.4

12

32

56

35

12x1.25
12x1.75

13

22.23

1,650

98

POS 14 RF/LF
POS 14 R/L

14

19

16.8

14

36

63

37

14x1.5
14x2.0

15

25.40

2,040

138

POS 16 RF/LF
POS 16 R/L

16

21

19.3

15

39

67

40

16x1.5
16x2.0

15

28.58

2,470

191

POS 18 R/L

18

23

21.8

17

44

76

46

18x1.5

15

31.75

2,910

280

POS 20 R/L

20

25

24.3

18

47

79

48

20x1.5

15

34.93

3,390

340

POS 22 R/L

22

28

25.9

20

50

84

51

22x1.5

15

38.10

4,070

475

POS 25 R/L

25

31

29.6

22

56

94

57

24x2.0

15

42.85

7,170

650

POS 30 R/L

30

37

34.8

26

67

110

66

30x2.0

15

50.80

9,120

1,070
