ANC-8T轴承尺寸规格

SAE NO.

AURORA NO.

DIMENSIONSIN INCHES

GROOVED

PLAIN

GROOVED

PLAIN

B

+.0000

-.0005

D

+.0000

-.0005

W

+.000

-.002

H

±.005

O

MIN.

P

+.000

-.010

G

+.000

-.008

R‡

+.002

-.005

Ball Dia.

Ref.

MS14101-3

MS14104-3

ANC-3TG

ANC-3T

.1900

.5625

.281

.218

.293

.025

.500

.010

.406

MS14101-4

MS14104-4

ANC-4TG

ANC-4T

.2500

.6562

.343

.250

.364

.025

.594

.010

.500

MS14101-5

MS14104-5

ANC-5TG

ANC-5T

.3125

.7500

.375

.281

.419

.035

.650

.010

.562

MS14101-5A

-

ANC-5TGA

-

.3125

.7500

.375

.281

.419

.035

.660

.010

.562

MS14101-6

MS14104-6

ANC-6TG

ANC-6T

.3750

.8125

.406

.312

.475

.035

.712

.015

.625

MS14101-7

MS14104-7

ANC-7TG

ANC-7T

.4375

.9062

.437

.343

.530

.035

.806

.015

.687

MS14101-8

MS14104-8

ANC-8TG

ANC-8T

.5000

1.0000

.500

.390

.600

.055

.876

.015

.781

MS14101-9

MS14104-9

ANC-9TG

ANC-9T

.5625

1.0937

.562

.437

.670

.055

.970

.015

.875

MS14101-10

MS14104-10

ANC-10TG

ANC-10T

.6250

1.1875

.625

.500

.739

.055

1.063

.015

.968

MS14101-12

MS14104-12

ANC-12TG

ANC-12T

.7500

1.4375

.750

.593

.920

.055

1.313

.015

1.187

MS14101-14

MS14104-14

ANC-14TG

ANC-14T

.8750

1.5625

.875

.703

.980

.055

1.438

.015

1.312

MS14101-16

MS14104-16

ANC-16TG

ANC-16T

1.0000

1.7500

1.000

.797

1.118

.055

1.626

.015

1.500
