1-11/16B/P12262 KG4大风量风机轴承轴承尺寸规格 |
Fafnir RAS pillow blocks are recommended for industrial
applications where normal loads are encountered. They
assure the user the advantages of a compact, one piece
housing which can be mounted in any position. The pillow
blocks are self-aligning at mounting with the spherical outside
diameter of the bearing fitting into a corresponding spherical
housing seat. These units are prelubricated and ready for
immediate installation. A grease fitting provides for
relubrication if required. Self-locking collars are supplied with
all units.
The RAS pillow blocks are equipped with G–KRRB
(R–Seal) wide inner ring bearings.
Bearing Data
Unit Bearing Number Dimensions Load Ratings
RAS G....KRRB Page 8, 9 Page 45
Recommended shaft tolerances : 1/2”to 1 15/16”, nominal to –0.0005” (0.013mm)
2” to 2 15/16”, nominal to –0.0010” (0.025mm)
To order, specify Unit and Shaft Diameter. Example: RAS1”
Unit Shaft Basic H H2 B1 J L A H1 N N1 d1 S1 T Bolt Bearing Collar Unit
Diam. Bearing Size Number Number Wt.
Number
in. in in. in. in. in. in. in. in. in. in. in. in.
mm mm mm mm mm mm mm mm mm mm mm mm mm mm kg
RAS 1/2 G1008KRRB S1008K
RAS 9/16 13/16 27/32 115/32 35/8 47/8 13/16 15/32 7/16 7/8 11/8 59/64 19/32 G1009KRRB S1009K
RAS 5/8 203 30.16 56.4 37.3 92.1 123.8 30.2 11.9 11.1 22.2 28.6 23.4 15.1 10 G1010KRRB S1010K 0.454
RAS 11/16 G1011KRRB S1011K
RAS 17 GE17KRRB SE17K
RAS 3/4
204
15/16 217/32 123/32 325/32 5 11/4 17/32 7/16 25/32 15/16 13/64 5/8 G1012KRRB S1012K
RAS 20 33.34 64.3 43.7 96 127 31.8 13.5 11.1 19.8 33.3 26.6 15.9 10 GE20KRRB SE20K 0.635
RAS 13/16 G1013KRRB S1013K
RAS 7/8 G1014KRRB S1014K
RAS 15/16 205 17/16 213/16 13/4 41/8 51/2 113/32 19/32 7/16 13/16 11/2 11/16 45/64 10 G1015KRRB S1015K 0.803
RAS 1 36.51 71.4 44.4 104.8 139.7 35.7 15.1 11.1 20.6 38.1 27 17.9 G1100KRRB S1100K
RAS 25 GE25KRRB SE25K
RAS 11/16 G1101KRRB S1101K
RAS 11/8
206
111/16 39/32 129/32 45/8 63/16 19/16 21/32 9/16 15/16 13/4 13/16 25/32 G1102KRRB S1102K
RAS 13/16 42.86 83.3 48.4 117.5 157.2 39.7 16.7 14.3 23.8 44.5 30.2 19.9 12 G1103KRRB S1103K 1.297
RAS 30 GE30KRRB SE30K
RAS 11/4 G1104KRRB S1104K
RAS 15/16 17/8 311/16 21/64 51/8 69/16 125/32 23/32 9/16 31/32 21/8 19/32 57/64 G1105KRRB S1105K
RAS 13/8 207 47.62 93.7 51.2 130.2 166.7 45.2 18.3 14.3 24.6 54 32.5 22.7 12 G1106KRRB S1106K 1.674
RAS 17/16 G1107KRRB S1107
RAS 35 GE35KRRB SE35K |
近期推荐轴承型号1-11/16B/P12262 KG4大风量风机轴承,
,
2MMV9108HXZZDULFS637,
206KPR4,
RCJC1-1/4 Sm,
SCJ5/8,
5307W,
2MMC9107WIDUL,
3MMV9107HXVVSUL,
7218WNSU,
DSP4,
GDW4K2,
以上为我司部分轴承型号，如需查找其他型号，可登陆我们的现货中心栏目或致电021-52797858转8008询价,进行详细查询，谢谢！
|
| 1-11/16B/P12262 KG4大风量风机轴承产品详细图片： |
 |
| FAFNIR轴承品牌介绍： |
| FAFNIR轴承历经一世纪考验,始终在美国业界占有一席之地。FAFNIR轴承隶属于美国TIMKEN公司,以生产各类球轴承享誉,FAFNIR的高精度主轴轴承,带座球轴承,AIRFRAME飞机控制用球,滚针,关节轴承,广泛用于工业和航天业界。FAFNIR直线运动滚动支承分为直线运动球轴承和滚动导轨支承。滚动轴承附件包括紧定套、退卸衬套、滚动轴承座、外球面轴承座等。主要生产以球轴承为主的多种精密轴承产品。 |
上海川代轴承机械有限公司专业销售FAFNIR轴承 1-11/16B/P12262 KG4大风量风机轴承轴承,FAFNIR轴承品牌供应商,我们为您提供1-11/16B/P12262 KG4大风量风机轴承的具体的规格参数及报价，本公司同时销售包括FAFNIR轴承品牌在内的多种进口轴承，包括深沟球轴承、自动调心球轴承、角接触球轴承、圆柱滚子轴承、滚针轴承、球面滚子轴承、推力轴承、Y-轴承、滚轮轴承，直线轴承，滑动轴承，轴承箱及各种精密机械部件等产品，目前公司拥有现货库存、快捷的物流体系、能在较短的时间内为用户解决轴承的配套供应和提供个性化服务。
欢迎垂询FAFNIR轴承 1-11/16B/P12262 KG4大风量风机轴承轴承价格和库存信息。咨询热线：021-52797858转8008询价 |
